Mat.No. 1.1158, DIN Ck25, AISI 1023
Designation by Standards Mat. No. DIN EN AISI 1.1158 Ck25 - 1023 Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others 0.25 max.0.40 0.55 max. 0.40 max. 0.10 max. 0.40 - - (Cr+Mo+Ni) = max. 0.63 Description Carbon steel, AISI 1000 series steel, low carbon steel. Applications For quenching and tempering, parts for machine building and vehicles. Physical properties (avarage values) at ambient temperature Modulus of elasticity [103 x N/...
Designation by Standards
Chemical Composition (in weight %)
|0.25||max.0.40||0.55||max. 0.40||max. 0.10||max. 0.40||-||-||(Cr+Mo+Ni) = max. 0.63|
Description Carbon steel, AISI 1000 series steel, low carbon steel. Applications For quenching and tempering, parts for machine building and vehicles. Physical properties (avarage values) at ambient temperature Modulus of elasticity [103 x N/mm2]: 200 Density [g/cm3]: 7.85 Thermal conductivity [W/m.K]: 51.2 Specific heat capacity[J/g.K]: 0.486 Soft Annealing Heat to 650-700oC, cool slowly. Normalizing Temperature: 880-920oC. Hardening Harden from a temperature of 860-900oC followed by water quenching. Tempering Tempering temperature: 550-660oC. Forging Hot forming temperature: 1100-850oC. Material Notes Machinability and weldability are fair. Cold formability of these steels is good to excellent. This grade responds favorably to heat treating and cold work. Forms manufactured: Please see the Dimensional Sales Program. Disclaimer The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available. Unless otherwise specified, registered trademarks are property of Metal Ravne company. Copyright 2015 by Metal Ravne. All rights reserved. Contact our Sales Office for more information.
