Mat.No. 1.0535, DIN C45, AISI 1055

Mat.No. 1.0535, DIN C45, AISI 1055

Short Description:

  Designation by Standards   Mat. No. DIN EN AISI 1.0535 C45 - 1055   Chemical Composition (in weight %)   C Si Mn Cr Mo Ni V W Others 0.56 max. 0.40 0.75 max. 0.40 max. 0.10 max. 0.40 - - (Cr+Mo+Ni)= max. 0.63   Description C55 is a medium carbon steel is used when greater strength and hardness is desired than in the “as rolled” condition. Extreme size accuracy, straightness and concentricity combine to minimize wear in high speed applicat...


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Port: Shenzhen
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    FAQ

    Product Tags



    Designation by Standards



    Mat. No. DIN EN AISI
    1.0535 C45 - 1055



    Chemical Composition (in weight %)



    C Si Mn Cr Mo Ni V W Others
    0.56 max. 0.40 0.75 max. 0.40 max. 0.10 max. 0.40 - - (Cr+Mo+Ni)= max. 0.63



    Description C55 is a medium carbon steel is used when greater strength and hardness is desired than in the “as rolled” condition. Extreme size accuracy, straightness and concentricity combine to minimize wear in high speed applications. Turned, ground and polished. Applications Quenched and subsequently tempered steel for less exacting springs, shafts, bushings, crankshafts, etc. Physical properties (avarage values) at ambient temperature Modulus of elasticity [103 x N/mm2]: 205 Density [g/cm3]: 7.85 Soft Annealing Heat to 650-700oC, cool slowly. This will produce a maximum Brinell hardness of 229. Normalizing Temperature: 825-865oC. Hardening Harden from a temperature of 805-845oC followed by water or oil quenching. Tempering Tempering temperature: 550-660oC. Mechanical Properties in Quenched+Tempered Condition



    Diameter (mm) 0.2 % proof stress (N/mm2) Tensile strength (N/mm2) Elongation A5(%) Reduction Z (%)
    up to 16 540 780-930 12 20
    17-40 460 740-890 14 30
    41-100 420 700-850 15 35



    Diagram Tempering Temperature – Mechanical Properties Forging Hot forming temperature: 1050-850oC. Machinability No data. Disclaimer The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
