Mat.No. 1.7335, DIN 13CrMo44, AISI A182 Grade F11

Mat.No. 1.7335, DIN 13CrMo44, AISI A182 Grade F11

Short Description:

Designation by Standards Brand Name Ravne No. Mat. No. DIN EN AISI 13CRMO44 762 1.7335 13CrMo44 13CrMo4-5 A 182 Grade F11 Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others 0.14 max. 0.40 0.55 0.98 0.60 - - - max. Cu = 0.30 DescriptionAlloy special structural steels. Cr-Mo-steels with > 0.35% Mo. ApplicationsHigh-temperature structural steel: Collectors, water boiler and superheater tubes (530oC). Physical properties (avarage values) at ambient temperatureModulu...


Product Detail

FAQ

Product Tags

Designation by Standards

Brand Name Ravne No. Mat. No. DIN EN AISI
13CRMO44 762 1.7335 13CrMo44 13CrMo4-5 A 182 Grade F11

Chemical Composition (in weight %)

C Si Mn Cr Mo Ni V W Others
0.14 max. 0.40 0.55 0.98 0.60 - - - max. Cu = 0.30

Description
Alloy special structural steels. Cr-Mo-steels with > 0.35% Mo.

Applications
High-temperature structural steel: Collectors, water boiler and superheater tubes (530oC).

Physical properties (avarage values) at ambient temperature
Modulus of elasticity [103 x N/mm2]: 210
Density [g/cm3]: 7.85

Soft Annealing
Heat to 680-720oC, cool slowly in furnace.

Hardening
Harden from a temperature of 910-940oC followed by oil or air quenching.

Tempering
Tempering temperature: 650-720oC.

Mechanical Properties in Hardened and Tempered Condition

Diameter in mm 0.2 % proof stress (N/mm2) Tensile strength (N/mm2) Elongation (%) Impact strength (J)
up to 60 295 440-590 20 44
61-90 285 440-590 20 44
91-150 275 440-590 20 44

0.2 % Proof Stress (N/mm2) vs. Temperature

100oC 150oC 200oC 250oC 300oC 350oC 400oC 450oC 500oC
260 245 240 230 215 200 190 180 175
250 240 230 220 205 190 180 170 165
250 235 220 210 195 180 170 160 155

1 % Creep Limit (N/mm2) vs. Temperature (oC)

Hours 450oC 460oC 480oC 500oC 520oC 540oC 560oC
10 000 245 228 193 157 122 90 64
100 000 191 172 133 98 70 46 30

Creep Rapture Strength (N/mm2) vs. Temperature (oC)

Hours 450oC 460oC 480oC 500oC 520oC 540oC 560oC
10 000 370 348 304 239 179 129 91
100 000 285 251 190 137 94 61 40
200 000 260 226 167 115 76 50 32

Forging
Hot forming temperature: 1100-850oC.

Machinability
No data.

Forms manufactured: Please see the Dimensional Sales Program.

Disclaimer
The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.

  • Previous:
  • Next:
  • FAQ Content

    Send your message to us:

    Related Products
