Mat.No. 1.2332, DIN 47CrMo4
Designation by Standards Brand Name Ravne No. Mat. No. DIN EN AISI VCMO145 234 1.2332 47CrMo4 - - Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others 0.47 0.25 0.70 1.05 0.33 - - - - DescriptionAlloyed tool steel. ApplicationsIndustry of plastics, for quenching and tempering, oil industry. Physical properties (avarage values) at ambient temperatureModulus of elasticity [103 x N/mm2]: 210 Density [g/cm3]: 7.86 Soft AnnealingHeat to 680-720oC, cool slo...
Designation by Standards
|Brand Name||Ravne No.||Mat. No.||DIN||EN||AISI|
Chemical Composition (in weight %)
Alloyed tool steel.
Industry of plastics, for quenching and tempering, oil industry.
Physical properties (avarage values) at ambient temperature
Modulus of elasticity [103 x N/mm2]: 210
Density [g/cm3]: 7.86
Heat to 680-720oC, cool slowly. This will produce a maximum Brinell hardness of 223.
Harden from a temperature of 830-890oC followed by oil or water quenching.
Tempering temperature: 540-680oC.
Hot forming temperature: 1050-850oC.
Forms manufactured: Please see the Dimensional Sales Program.
The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
