Mat.No. 1.7337, DIN 16CrMo4-4, AISI A182 (F12 Cl.2)

Mat.No. 1.7337, DIN 16CrMo4-4, AISI A182 (F12 Cl.2)

Short Description:

Designation by Standards Brand Name Ravne No. Mat. No. DIN EN AISI 17CRMO55 713 1.7337 16CrMo4-4 - A182 (F12 Cl.2) Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others 0.16 0.25 0.65 1.05 0.45 max. 0.40 - - - DescriptionSpecial structural steel. ApplicationsComponent parts for steam boilers and turbines, shafts for higher temperature ranges. Physical properties (avarage values) at ambient temperatureModulus of elasticity [103 x N/mm2]: 210 Density [g/cm3]: ...


Product Detail

FAQ

Product Tags

Designation by Standards

Brand Name Ravne No. Mat. No. DIN EN AISI
17CRMO55 713 1.7337 16CrMo4-4 - A182 (F12 Cl.2)

Chemical Composition (in weight %)

C Si Mn Cr Mo Ni V W Others
0.16 0.25 0.65 1.05 0.45 max. 0.40 - - -

Description
Special structural steel.

Applications
Component parts for steam boilers and turbines, shafts for higher temperature ranges.

Physical properties (avarage values) at ambient temperature
Modulus of elasticity [103 x N/mm2]: 210
Density [g/cm3]: 7.85

Soft Annealing
Heat to 650-720oC, cool slowly in furnace.

Hardening
Harden from a temperature of 900-950oC followed by oil quenching.

Tempering
Tempering temperature: 650-720oC.

Forging
Hot forming temperature: 1100-850oC.

Machinability
No data.

Forms manufactured: Please see the Dimensional Sales Program.

Disclaimer
The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
