Mat.No. 1.0570, DIN St52-3, AISI 1024

Mat.No. 1.0570, DIN St52-3, AISI 1024

Short Description:

Designation by Standards Mat. No. DIN EN AISI 1.0570 St52-3 - 1024 Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others max. 0.20 max. 0.55 max. 1.60 - - - - - - Description Non alloy quality steels: Steels with average C > 0,25 < 0,55 % or Rm > 500 < 700 N/mm2. Applications Materials for rail vehicles. Structural steels and structural steels with improved atmospheric corrosion resistance, hot rolled.  Physical properties (avarage values) at ambient tempe...


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Port: Shenzhen
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    FAQ

    Product Tags

    Designation by Standards

    Mat. No. DIN EN AISI
    1.0570 St52-3 - 1024

    Chemical Composition (in weight %)

    C Si Mn Cr Mo Ni V W Others
    max. 0.20 max. 0.55 max. 1.60 - - - - - -

    Description Non alloy quality steels: Steels with average C > 0,25 < 0,55 % or Rm > 500 < 700 N/mm2. Applications Materials for rail vehicles. Structural steels and structural steels with improved atmospheric corrosion resistance, hot rolled.  Physical properties (avarage values) at ambient temperature Modulus of elasticity [103 x N/mm2]: 210 Density [g/cm3]: 7.85 Normalizing Normalizing temperature: 890-950oC. Forging Hot forming temperature: 1050-850oC.  Machinability No data. Forms manufactured: Please see the Dimensional Sales Program.  Disclaimer The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available. Unless otherwise specified, registered trademarks are property of Metal Ravne company. Copyright 2015 by Metal Ravne. All rights reserved. Contact our Sales Office for more information.
