E235 ( 1.0308 )

E235   ( 1.0308 )

Short Description:

  Grade :     E235     Number:     1.0308     Classification:     Non-alloy quality steel     Standard:     EN 10296-1: 2003 Welded circular steel tubes for mechanical and general engineering purposes. Non-alloy and alloy steel tubes. Technical delivery conditions     EN 10305-1: 2010 Steel tubes for precision applications. Seamless cold drawn tubes. Technical delivery conditions     EN 10305-2: 2002 Steel tubes for precision applications. Welded cold drawn tubes. Technical d...


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Port: Shenzhen
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    FAQ

    Product Tags

      Grade :     E235
        Number:     1.0308
        Classification:     Non-alloy quality steel
        Standard:
        EN 10296-1: 2003 Welded circular steel tubes for mechanical and general engineering purposes. Non-alloy and alloy steel tubes. Technical delivery conditions
        EN 10305-1: 2010 Steel tubes for precision applications. Seamless cold drawn tubes. Technical delivery conditions
        EN 10305-2: 2002 Steel tubes for precision applications. Welded cold drawn tubes. Technical delivery conditions
        EN 10305-3: 2002 Steel tubes for precision applications. Welded cold sized tubes. Technical delivery conditions
        EN 10305-4: 2003 Steel tubes for precision applications. Seamless cold drawn tubes for hydraulic and pneumatic power systems. Technical delivery conditions
        EN 10305-5: 2003 Steel tubes for precision applications. Welded and cold sized square and rectangular tubes. Technical delivery conditions
        EN 10297-1: 2003 Seamless circular steel tubes for mechanical and general engineering purposes. Non-alloy and alloy steel tubes. Technical delivery conditions

    Chemical composition %   of   steel   E235 (1.0308):   EN 10296-1-2003

    P max =0.025%; S max =0.025%; Al min =0.02% (EN 10305-1:2010)

    C Si Mn P S
    max   0.17 max   0.35 max   1.2 max   0.045 max   0.045


    Rm - Tensile strength (MPa) (+U) 390
    Rm - Tensile strength (MPa) (+A) 315
    Rm - Tensile strength (MPa) (+N) 340-480
    Nominal thickness (mm): to 16 16 – 40 40 – 65 65 – 100
    Rm - Tensile strength (MPa) (+AR) 360 360 360 340
    Rm - Tensile strength (MPa) (+SR) 420-440
    Rm - Tensile strength (MPa) (+C) 480-490
    Rm - Tensile strength (MPa) (+LC) 440
    ReH - Minimum yield strength (MPa) (+U) 300
    ReH - Minimum yield strength (MPa) (+N) 235
    Nominal thickness (mm): to 16 16 – 40 40 – 65 65 – 80 80 – 100
    ReH - Minimum yield strength (MPa) (+AR) 235 225 215 205 195
    ReH - Minimum yield strength (MPa) (+SR) 325-350
    A - Min. elongation at fracture (%) (+A) or (+N) 25
    A - Min. elongation at fracture (%) (+U) 7
    A - Min. elongation at fracture (%) (+C) 6
    A - Min. elongation at fracture (%) (+LC) 10
    A - Min. elongation at fracture (%) (+SR) 14-16
