Short Description:

Q125 API 5CT Casing /Tubing suppliers, Q125 Oil And Gas Api Casing Pipe, Q125 Api Oilfield Casing Pipe, Q125 Api Steel Casing Pipe, Q125 Api Casing /Tubing, Nue Api Tubing, Eue Api Tubing, Grade Q125 Oil Well Drilling Casing Pipe API 5CT Q125 Casing Specification Casing Pipe Specifications Standards:   API SPEC 5CT Model in Common Use:   2-3/8″, 2-7/8″, 3-1/2″, 4″, 4-1/2″ Length Range:   R1(6.10-7.32m), R2(8.53-9.75m), R3(11.58-12.8m) Steel Grade (Casi...


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Port: Shenzhen
  • Payment Terms: L/C,D/A,D/P,T/T
    • Download as PDF

    Product Detail

    FAQ

    Product Tags

    Q125 API 5CT Casing /Tubing suppliers, Q125 Oil And Gas Api Casing Pipe, Q125 Api Oilfield Casing Pipe, Q125 Api Steel Casing Pipe, Q125 Api Casing /Tubing, Nue Api Tubing, Eue Api Tubing, Grade Q125 Oil Well Drilling Casing Pipe

    API 5CT Q125 Casing Specification

    Casing Pipe Specifications
    Standards:   API SPEC 5CT
    Model in Common Use:   2-3/8″, 2-7/8″, 3-1/2″, 4″, 4-1/2″
    Length Range:   R1(6.10-7.32m), R2(8.53-9.75m), R3(11.58-12.8m)
    Steel Grade (Casing Grades, Tubing Grades):   J55, K55, N80-1, N80-Q, L80, P110
    Type of Screw Thread:   Non upset threaded end(NUE), External upset threaded end(EUE)
    Specialties
    • Threading
    • Heat treating
    • External upset
    • Drifting (Full-length, or just ends)
    • Hydrostatic Testing
    • Full third-party inspection capabilities (EMI, SEA, and Weld Line)
    • Couplings – EUE, AB Modified, turned down, special clearance couplings
    • Coating to customer specifications
    • Pup Joints



    PRODUCT GRADE DIAMETER END TYPE
    Q125 TUBING J55, JFBNAU, L80, P110, 1% Chrome 2.375″ – 3.5″ Plain End
    EUE 8RD
    Q125 CASING J-55, L80 HC, P110 HC 4.5″ – 9.625″ (J55, L80 HC, P110 HC) 10.75” – 20” (J55) Plain End, STC, LTC, BTC

    Q125 TUBING SIZES, CASING DRIFT SIZES AND AVAILABLE GRADES:

    OD Wall PE # / ft T&C # / ft Collar API Drift Available Grades
    2.375″ .190 4.44 4.7 EUE,
    AB MOD    		 1.901 J55, J-FBNAU, N80, L80, P110
    2.875″ .217 6.17 6.5 EUE,
    AB MOD    		 2.347 J55, J-FBNAU, N80, L80, P110
    3.5″ .254 8.81 9.3 EUE,
    AB MOD    		 2.867 J55, J-FBNAU, N80, L80, P110

    Casing Sizes And Grades, Casing And Tubing Dimensions

    Pipe Casing Sizes, Oilfield Casing Sizes & Casing Drift Sizes
    Outer Diameter (Casing Pipe Sizes) 4 1/2″-20″, (114.3-508mm)
    Standard Casing Sizes 4 1/2″-20″, (114.3-508mm)
    Thread Type Buttress thread casing, Long round thread casing, Short round thread casing
    Function It can protect the tubing pipe.

    Oil Tube For Petroleum And Natural Gas Industries

    Name of Pipes Specification Steel Grade Standard
    D (S) (L)
    (mm) (mm) (m)
    Petroleum Casing Pipe

    127-508

    5.21-16.66

    6-12

    J55. M55. K55.
    L80. N80. P110.

    		 API Spec 5CT (8)
    Petroleum Tubing

    26.7-114.3

    2.87-16.00

    6-12

    J55. M55. K55.
    L80. N80. P110.

    		 API Spec 5CT (8)
    Coupling

    127-533.4

    12.5-15

    6-12

    J55. M55. K55.
    L80. N80. P110.

    		 API Spec 5CT (8)
