Mat.No. 1.2604, DIN 73WCrMoV2-2
Designation by Standards Mat. No. DIN EN AISI 1.2604 73WCrMoV2-2 - - Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others 0.73 0.30 0.50 0.50 0.33 - 0.23 0.55 - Description Low alloyed cold working tool steel. Applications Tap drills, broaching tools, milling cutters and other cutting tools. It is usually supplied as silver steel. Physical properties (avarage values) at ambient temperature Modulus of elasticity [103 x N/mm2]: 210 De...
Designation by Standards
Chemical Composition (in weight %)
Low alloyed cold working tool steel.
Tap drills, broaching tools, milling cutters and other cutting tools. It is usually supplied as silver steel.
Physical properties (avarage values) at ambient temperature
Modulus of elasticity [103 x N/mm2]: 210
Density [g/cm3]: 7.80
Continuous Cooling Transformation (CCT) Diagram
Time-Temperature Transformation (TTT) Diagram
Heat to 680-710oC, cool slowly. This will produce a maximum Brinell hardness of 225.
Harden from a temperature of 810-840oC followed by oil quenching.Hardness after quenching is 63 HRC.
Tempering temperature: 180-300oC.
Hot forming temperature: 1050-900oC.
The machinability rating of D3 is roughly 25 % that of free machining carbon steel 1018. Due to its abrasion resistant nature, machining in the hardened condition should be limited to finish grinding.
The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
