Mat.No. 1.2210, DIN 115CrV3, AISI L2
Short Description:
Designation by Standards Mat. No. DIN EN AISI 1.2210 115CrV3 - L2 Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others 1.17 0.23 0.30 0.65 - - 0.10 - - Description Low alloyed cold working tool steel. Applications Spiral and tap drills, broaching tools, engraving tools, ejectors, metal saws. Physical properties (avarage values) at ambient temperature Modulus of elasticity [103 x N/mm2]: 210 Density [g/cm3]: 7.80 Thermal conductivity [W/m.K]: 33.5, 32 (500oC), 31 (7...
Product Detail
FAQ
Product Tags
Designation by Standards
Mat. No. | DIN | EN | AISI |
1.2210 | 115CrV3 | - | L2 |
Chemical Composition (in weight %)
C | Si | Mn | Cr | Mo | Ni | V | W | Others |
1.17 | 0.23 | 0.30 | 0.65 | - | - | 0.10 | - | - |
Description
Low alloyed cold working tool steel.
Applications
Spiral and tap drills, broaching tools, engraving tools, ejectors, metal saws.
Physical properties (avarage values) at ambient temperature
Modulus of elasticity [103 x N/mm2]: 210
Density [g/cm3]: 7.80
Thermal conductivity [W/m.K]: 33.5, 32 (500oC), 31 (700oC)
Electric resistivity [Ohm mm2/m]: 0.33
Specific heat capacity[J/g.K]: 0.46
Coefficient of Linear Thermal Expansion 10-6 oC-1
20-100oC | 20-200oC | 20-300oC | 20-400oC | 20-500oC |
11.8 | 12.5 | 12.9 | 13.5 | 13.7 |
Soft Annealing
Heat to 710-850oC, cool slowly in furnace. This will produce a maximum Brinell hardness of 223.
Stress Relieving
Stress relieving to remove machining stresses should be carried out by heating to approx. 650oC, holding for 1-2 hours at heat, followed by air cooling. This operation is performed to reduce distortion during heat treatment.
Hardening
Harden from a temperature of 780-820oC, 800-840oC followed by water or oil quenching. Hardness after quenching is 64-66, 64-66 HRC.
Tempering
Tempering temperature: 100-400oC.
Tempering Temperature (oC) vs. Hardness (HRC)
100oC | 200oC | 300oC | 400oC | 450oC |
64 | 63 | 59 | 54 | 47 |
Tempering Diagram
Forging
Hot forming temperature: 1050-850oC.
Machinability
No data.
Corrosion Resistance
This is an alloy steel and it is not corrosion resistant. It will rust unless protected.
Disclaimer
The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
