Mat.No. 1.0913 50Mn7
Designation by Standards Brand Name Ravne No. Mat. No. DIN EN AISI 2MN 568 1.0913 50Mn7 - - Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others 0.50 max. 0.40 1.80 - - - - - max. N = 0.007 DescriptionAlloy quality steels. Steels for various applications. ApplicationsLeaf and conical spiral springs, parts for conveyor units, railway tracks, etc. Physical properties (avarage values) at ambient temperatureModulus of elasticity [103 x N/mm2]: 210 Density [g/cm...
Designation by Standards
|Brand Name||Ravne No.||Mat. No.||DIN||EN||AISI|
Chemical Composition (in weight %)
|0.50||max. 0.40||1.80||-||-||-||-||-||max. N = 0.007|
Alloy quality steels. Steels for various applications.
Leaf and conical spiral springs, parts for conveyor units, railway tracks, etc.
Physical properties (avarage values) at ambient temperature
Modulus of elasticity [103 x N/mm2]: 210
Density [g/cm3]: 7.85
Heat to 680-700oC, cool slowly. This will produce a maximum Brinell hardness of 225.
Harden from a temperature of 790-830oC followed by oil quenching.
Tempering temperature: 450-520oC, 550-650oC.
Click the image to enlarge the diagram.
Hot forming temperature: 1050-850oC.
Forms manufactured: Please see the Dimensional Sales Program.
The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
