DIN 17100 St 37-2 steel
Short Description:
DIN 17100 St 37-2 steel equivalent grade: St 37-2 steel plate/sheet is in DIN 17100 standard, the material number is 1.0037. The equivalent grade of St 37-2 steel are EN 10025 EN 10025, NFA 35-501 E 24-2, UNI 7070 Fe 360 B, BS 4360 40 A, ASTM A 283 C – A 570 Gr. 33. St 37-2 DIN 17100 Material #:1.0037 Comparison of steel grades EN 10025 S235JR NFA 35-501 E 24-2 UNI 7070 Fe 360 B BS 4360 40 A ASTM A 283 C – A 570 Gr. 33 DIN 17100 St 37-2 steel chemical composition %...
Product Detail
FAQ
Product Tags
DIN 17100 St 37-2 steel equivalent grade:
St 37-2 steel plate/sheet is in DIN 17100 standard, the material number is 1.0037. The equivalent grade of St 37-2 steel are EN 10025 EN 10025, NFA 35-501 E 24-2, UNI 7070 Fe 360 B, BS 4360 40 A, ASTM A 283 C – A 570 Gr. 33.
| St 37-2 DIN 17100 Material #:1.0037 |
Comparison of steel grades | |
| EN 10025 | S235JR | |
| NFA 35-501 | E 24-2 | |
| UNI 7070 | Fe 360 B | |
| BS 4360 | 40 A | |
| ASTM | A 283 C – A 570 Gr. 33 | |
DIN 17100 St 37-2 steel chemical composition %:
Main chemical composition in DIN 17100 St 37-2 steel is carton max 0.17, manganese max 1.40, phosphorus max 0.045, sulphur max 0.045. More detailed information about DIN 17100 St 37-2 steel, please refer to the down table:
| Chemical elements | C≤ 16mm max |
C>16mm max |
Si max |
Mn max |
P max. |
S max. |
| %,by mass | 0.17 | 0.17 | – | 1.40 | 0.045 | 0.045 |
DIN 17100 St 37-2 steel mechanical property:
St37-2 steel plate is one mainly of Carbon steel, St37-2 is a type of steel sheet under EN standard which is used to build ship, bridge, belongs to high strength sheet.
| thickness | Yield StrengthReH[N/mm2] transv.min. |
TensileStrengthRm[N/mm2]transv. | Fracture Elongation[%]transv. min. | Notch Impact Energy1)Ch Vcomplete samplelongitud. min [J] |
| t ≤ 16mm t > 16mm |
235 225 |
Degree: 0 AV: 27J |
||
| t < 3mm t ≥ 3mm |
360-510 340-470 |
|||
| Up to 1.5mm 1.51-2.00mm 2.01-2.50mm 2.51-2.99mm ≥ 3mm |
16 17 18 19 24 |
