Mat.No. 1.7734

Mat.No. 1.7734

Short Description:

Designation by Standards Brand Name Ravne No. Mat. No. DIN EN AISI PO795 795 1.7734 - 15CDV6 - Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others 0.15 max. 0.20 0.95 1.38 0.90 - 0.25 - - DescriptionThis is chromium-molybdenum-vanadium Structural steels. Good bending performance and excellent weldability. Toughness, consistency and resistance to fatique derived from the high level of micro cleanliness. ApplicationsComponent parts for the aircraft industry.  Phy...


Product Detail

FAQ

Product Tags

Designation by Standards

Brand Name Ravne No. Mat. No. DIN EN AISI
PO795 795 1.7734 - 15CDV6 -

Chemical Composition (in weight %)

C Si Mn Cr Mo Ni V W Others
0.15 max. 0.20 0.95 1.38 0.90 - 0.25 - -

Description
This is chromium-molybdenum-vanadium Structural steels. Good bending performance and excellent weldability. Toughness, consistency and resistance to fatique derived from the high level of micro cleanliness.

Applications
Component parts for the aircraft industry.

Physical properties (avarage values) at ambient temperature
Modulus of elasticity [103 x N/mm2]: 190-210
Density [g/cm3]: 7.80

Continuous Cooling Transformation (CCT) Diagram


Click the image to enlarge the diagram.

Time-Temperature Transformation (TTT) Diagram


Click the image to enlarge the diagram.

Soft Annealing
Please ask.

Stress Relieving
Stress relieving to remove machining stresses should be carried out by heating to 600-650oC, holding for 1-2 hours at heat, followed by air cooling. This operation is performed to reduce distortion during heat treatment.

Hardening
Quenching temperature: 975oC.

Tempering
Temperature: 600-740oC.

Forging
Hot forming temperature: 1050-850oC.

Machinability
No data.

Forms manufactured: Please see the Dimensional Sales Program.

Disclaimer
The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
