Mat.No. 1.7262, DIN 15CrMo5

Mat.No. 1.7262, DIN 15CrMo5

Short Description:

Designation by Standards Brand Name Ravne No. Mat. No. DIN EN AISI ECMO80 720 1.7262 15CrMo5 - - Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others 0.15 0.25 0.95 1.15 0.25 - - - - DescriptionAlloyed carbon steel. ApplicationsHigh wear resistant parts, pins, driving shafts, gears, gear wheels, bolts, bushings, etc. Physical properties (avarage values) at ambient temperatureModulus of elasticity [103 x N/mm2]: 210 Density [g/cm3]: 7.83 Soft AnnealingHeat t...


Product Detail

FAQ

Product Tags

Designation by Standards

Brand Name Ravne No. Mat. No. DIN EN AISI
ECMO80 720 1.7262 15CrMo5 - -

Chemical Composition (in weight %)

C Si Mn Cr Mo Ni V W Others
0.15 0.25 0.95 1.15 0.25 - - - -

Description
Alloyed carbon steel.

Applications
High wear resistant parts, pins, driving shafts, gears, gear wheels, bolts, bushings, etc.

Physical properties (avarage values) at ambient temperature
Modulus of elasticity [103 x N/mm2]: 210
Density [g/cm3]: 7.83

Soft Annealing
Heat to 680-700oC, cool slowly. This will produce a maximum Brinell hardness of 207.

Intermediate Annealing
Temperature: 650-680oC.

Carburizing
Temperature of 840-800oC, cooling media: salt bath 580-680oC, air, case hardening box, water, oil, hot quneching 160-250oC.

Core Hardening
Temperature: 820-850oC.

Surface Hardening
Temperature: 810-830oC, air or hot quenching.

Tempering
Tempering temperature: 150-180oC.

Forging
Hot forming temperature: 1050-850oC.

Machinability
No data.

Forms manufactured: Please see the Dimensional Sales Program.

Disclaimer
The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
