Mat.No. 1.5232, DIN 27MnSiVS6
Designation by Standards Brand Name Ravne No. Mat. No. DIN EN AISI 27MNSIVS6 108 1.5232 27MnSiVS6 - - Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others 0.28 0.65 1.45 - - - 0.1 - - DescriptionAlloy special structural steel. ApplicationsFor hardening “parts for dies” forgings. Physical properties (avarage values) at ambient temperatureModulus of elasticity [103 x N/mm2]: 210 Density [g/cm3]: 7.85 Soft AnnealingPlease ask. HardeningPlease...
Designation by Standards
|Brand Name||Ravne No.||Mat. No.||DIN||EN||AISI|
Chemical Composition (in weight %)
Alloy special structural steel.
For hardening “parts for dies” forgings.
Physical properties (avarage values) at ambient temperature
Modulus of elasticity [103 x N/mm2]: 210
Density [g/cm3]: 7.85
Hot forming temperature: 1100-850oC.
Forms manufactured: Please see the Dimensional Sales Program.
The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
