Short Description:

1. Supply Range of ASTM D6 Tool Steel D6 Steel Round Bar: diameter 8mm – 4000mm D6 Steel Plate: thickness 2mm –300mm x width 200mm – 800mm Other sizes of D6 oil steel or as per customer’s requirements Surface Finish: Black, Sand Blasting, Rough Machined, Peeled, Turned or as per given requirements. 2. Relevant Steel Specification of AISI D6 Tool Steel Country USA German Japan Standard ASTM A681 DIN EN ISO 4957 JIS G4404 Grades D6 1.2436 SKD2 3. AISI D6 Tool Steel Chemical Compositio...


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Port: Shenzhen
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    FAQ

    Product Tags

    1. Supply Range of ASTM D6 Tool Steel

    D6 Steel Round Bar: diameter 8mm – 4000mm
    D6 Steel Plate: thickness 2mm –300mm x width 200mm – 800mm
    Other sizes of D6 oil steel or as per customer’s requirements
    Surface Finish: Black, Sand Blasting, Rough Machined, Peeled, Turned or as per given requirements.

    2. Relevant Steel Specification of AISI D6 Tool Steel
    Country USA German Japan
    Standard ASTM A681 DIN EN ISO 4957 JIS G4404
    Grades D6 1.2436 SKD2

    3. AISI D6 Tool Steel Chemical Composition & Other Equivalents

    ASTM A681 C Mn P S Si Cr W
    D6 2.00 2.20 0.20 0.40 0.03 0.03 0.20 0.40 11.50 12.50 0.60 0.90
    DIN ISO 4957 C Mn P S Si Cr W
    1.2436 / X210CrW12 2.00 2.30 0.30 0.60 0.03 0.03 0.10 0.40 11.00 13.00 0.60 0.80
    JIS G4404 C Mn P S Si Cr W
    SKD2 2.00 2.30 0.30 0.60 0.03 0.03 0.10 0.60 11.00 13.00 0.60 0.80

    4. ASTM D6 Tool Steel Mechanical Properties

    • Physical Properties
    Properties Metric Imperial
    Density 7.67 g/cm3 0.277 lb/in3
    • Mechanical Properties
    Properties Metric Imperial
    Compressive strength 1320 MPa 191000 psi
    Modulus of elasticity 194 GPa 28100 ksi
    Hardness, Rockwell C 46 46
    • Thermal Properties
    Properties Metric Imperial
    Thermal expansion co-efficient (@21-400°C/68-752°F) 10.8 µm/m°C 6 µin/in°F
    Thermal conductivity (@20°C/68°F) 20.5 W/mK 142 BTU.in/hrft².°F

    5. Forging of D6 Steel

    D6 tool steel is heated slowly and uniformly to 700°C (1292°F) and then more rapidly to 900-1050°C (1652-1922°F).

    6. AISI/SAE D6 Tool Steel Heat Treatment

    Soft annealing ℃ Cooling Hardness HB
    800 – 840 Cool sloly in furnace max. 255
    Hardening from ℃ in Hardness after quenching HRC
    940 – 980 oil, air or warm bath 64 – 66
    960 – 1000 500 – 550 C 64 – 66
    Tempering 100 200 300 400 500 600
    HRC 63 62 60 58 56 48

    7. Applications for ASTM A681 D6 Tool Steel

    AISI/SAE D6 steel is used for blanking dies for cutting sheets up to 2mm thick, paper & plastic blades. Steel D6 is also suitable for the below applications:
    Blanking tools, stamping tools, embossing tools, scraping tools, trimming tools, woodworking tools, drawing tools, press tools, stone moulds, sintered tools, machine knives, hammer cores, ring rollers, thread rolling dies, plastic moulds.

    You are welcome to send your request of D6 tool steel, 1.2436 / X210CrW12 steel or SKD2 steel to us any time. We are ISO 9001 certified tool steel supplier. We are your better choice and long term business partner.
