Mat.No. 1.1013, DIN RFe100

Mat.No. 1.1013, DIN RFe100

Short Description:

  Designation by Standards   Mat. No. DIN EN AISI 1.1013 RFe100 - -   Chemical Composition (in weight %)   C Si Mn Cr Mo Ni V W Others max. 0.05 max. 0.10 0.28 - - - - - Al = 0.07   Description Non alloy special steels. Steel with special physical properties. Applications Soft magnetic materials for direct current relays. Physical properties (avarage values) at ambient temperature Modulus of elasticity [103 x N/mm2]: 210 Density [g/cm3]: 7.85 Soft Anne...


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Port: Shenzhen
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    FAQ

    Product Tags



    Designation by Standards



    Mat. No. DIN EN AISI
    1.1013 RFe100 - -



    Chemical Composition (in weight %)



    C Si Mn Cr Mo Ni V W Others
    max. 0.05 max. 0.10 0.28 - - - - - Al = 0.07



    Description Non alloy special steels. Steel with special physical properties. Applications Soft magnetic materials for direct current relays. Physical properties (avarage values) at ambient temperature Modulus of elasticity [103 x N/mm2]: 210 Density [g/cm3]: 7.85 Soft Annealing Brinell hardness in annealed condition is 80-135. Normalizing Please ask. Hardening Please ask. Tempering Please ask. Forging Hot forming temperature: 1050-850oC. Machinability No data. Forms manufactured: Please see the Dimensional Sales Program. Disclaimer The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available. Unless otherwise specified, registered trademarks are property of Metal Ravne company. Copyright 2015 by Metal Ravne. All rights reserved. Contact our Sales Office for more information.
