Mat.No. 1.6545, DIN 30NiCrMo2-2, AISI 8630H

Mat.No. 1.6545, DIN 30NiCrMo2-2, AISI 8630H

Short Description:

Designation by Standards Brand Name Ravne No. Mat. No. DIN EN AISI PO206 206 1.6545 30NiCrMo2-2 - 8630H Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others 0.31 0.28 0.85 0.50 0.23 0.55 - - - DescriptionAlloyed carbon steel. ApplicationsSeverely stressed components for mechanical engineering and automobile industry.  Physical properties (avarage values) at ambient temperatureModulus of elasticity [103 x N/mm2]: 210 Density [g/cm3]: 7.84 Soft Annealing...


Product Detail

FAQ

Product Tags

Designation by Standards

Brand Name Ravne No. Mat. No. DIN EN AISI
PO206 206 1.6545 30NiCrMo2-2 - 8630H

Chemical Composition (in weight %)

C Si Mn Cr Mo Ni V W Others
0.31 0.28 0.85 0.50 0.23 0.55 - - -

Description
Alloyed carbon steel.

Applications
Severely stressed components for mechanical engineering and automobile industry.

Physical properties (avarage values) at ambient temperature
Modulus of elasticity [103 x N/mm2]: 210
Density [g/cm3]: 7.84

Soft Annealing
Please ask.

Normalizing
Please ask.

Stress Relieving
Please ask.

Hardening
Please ask.

Tempering
Please ask.

Forging
Hot forming temperature: 1050-850oC.

Machinability
No data.

Forms manufactured: Please see the Dimensional Sales Program.

Disclaimer
The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
