Short Description:

Designation by Standards Mat. No. DIN EN AISI 1.2360 - - - Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others 0.47 0.80 0.40 7.50 1.37 - 1.35 - - Description Medium alloyed cold work tool steel with high toughness and wear resistance. Applications Severely stressed machine blades for cellulose and paper industry, woodworking milling cutters, flat and circular blades for cutting sheets/plates of thickness 5 to 15 mm.  Physical properties (avarage values) at ambient ...


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Port: Shenzhen
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    FAQ

    Product Tags

    Designation by Standards

    Mat. No. DIN EN AISI
    1.2360 - - -

    Chemical Composition (in weight %)

    C Si Mn Cr Mo Ni V W Others
    0.47 0.80 0.40 7.50 1.37 - 1.35 - -

    Description
    Medium alloyed cold work tool steel with high toughness and wear resistance.

    Applications
    Severely stressed machine blades for cellulose and paper industry, woodworking milling cutters, flat and circular blades for cutting sheets/plates of thickness 5 to 15 mm.

    Physical properties (avarage values) at ambient temperature
    Modulus of elasticity [103 x N/mm2]: 210
    Density [g/cm3]: 7.80

    Continuous Cooling Transformation (CCT) Diagram

    Time-Temperature Transformation (TTT) Diagram

    Hardening
    Harden from a temperature of 1080-1120oC followed by oil quenching.

    Tempering
    Tempering temperature: Please see the diagram bellow.

    Tempering Diagram

    Forging
    Hot forming temperature: 1100-900oC.

    Machinability
    No data.

    Disclaimer
    The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
