Mat.No. 1.1520, DIN C70, AISI 1070

Mat.No. 1.1520, DIN C70, AISI 1070

Short Description:

  Designation by Standards   Mat. No. DIN EN AISI 1.1520 C70 - 1070   Chemical Composition (in weight %)   C Si Mn Cr Mo Ni V W Others 0.70 0.20 0.25 - - - - - -   Description Unalloyed carbon steel. Applications Quenched and tempered steel for heavy duty parts in machines, vechicles. Physical properties (avarage values) at ambient temperature Modulus of elasticity [103 x N/mm2]: 210 Density [g/cm3]: 7.85 Soft Annealing Heat to 680-710oC, cool slowly. ...


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Port: Shenzhen
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    FAQ

    Product Tags



    Designation by Standards



    Mat. No. DIN EN AISI
    1.1520 C70 - 1070



    Chemical Composition (in weight %)



    C Si Mn Cr Mo Ni V W Others
    0.70 0.20 0.25 - - - - - -



    Description
    Unalloyed carbon steel.

    Applications
    Quenched and tempered steel for heavy duty parts in machines, vechicles.

    Physical properties (avarage values) at ambient temperature
    Modulus of elasticity [103 x N/mm2]: 210
    Density [g/cm3]: 7.85

    Soft Annealing
    Heat to 680-710oC, cool slowly. This will produce a maximum Brinell hardness of 183.

    Hardening
    Harden from a temperature of 790-820oC followed by water. Hardness after quenching is 63-64 HRC.

    Tempering
    Tempering temperature: 180-300oC.

    Forging
    Hot forming temperature: 1100-850oC.

    Machinability
    No data.

    Disclaimer
    The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
