Mat.No. 1.1193, DIN CF45, AISI 1045

Mat.No. 1.1193, DIN CF45, AISI 1045

Short Description:

  Designation by Standards   Mat. No. DIN EN AISI 1.1193 CF45 - 1045   Chemical Composition (in weight %)   C Si Mn Cr Mo Ni V W Others 0.46 0.25 0.65 - - - - - -   Description CF45 is a medium carbon steel is used when greater strength and hardness is desired than in the “as rolled” condition. Extreme size accuracy, straightness and concentricity combine to minimize wear in high speed applications. Turned, ground and polished. Applications...


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Port: Shenzhen
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    FAQ

    Product Tags



    Designation by Standards



    Mat. No. DIN EN AISI
    1.1193 CF45 - 1045



    Chemical Composition (in weight %)



    C Si Mn Cr Mo Ni V W Others
    0.46 0.25 0.65 - - - - - -



    Description CF45 is a medium carbon steel is used when greater strength and hardness is desired than in the “as rolled” condition. Extreme size accuracy, straightness and concentricity combine to minimize wear in high speed applications. Turned, ground and polished. Applications Used in gears, shafts, axles, bolts, studs, and machine parts. Physical properties (avarage values) at ambient temperature Modulus of elasticity [103 x N/mm2]: 210 Density [g/cm3]: 7.85 Soft Annealing Heat to 650-700oC, cool slowly. This will produce a maximum Brinell hardness of 207. Normalizing Temperature: 840-870oC. Stress Relieving Stress relieving to remove machining stresses should be carried out by heating to 120-200oC, holding for one hour at heat, followed by air cooling. This operation is performed to reduce distortion during heat treatment. Hardening Harden from a temperature of 820-850oC followed by oil or water quenching. Hardness after quenching is 55-61 HRC. Tempering Tempering temperature: 550-660oC. Forging Hot forming temperature: 1100-850oC. Machinability No data. Disclaimer The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
