Mat.No. 1.0540, DIN C50, AISI 1050

Mat.No. 1.0540, DIN C50, AISI 1050

Short Description:

  Designation by Standards   Brand Name Ravne No. Mat. No. DIN EN AISI C50 522 1.0540 C50 - 1050   Chemical Composition (in weight %)   C Si Mn Cr Mo Ni V W Others 0.51 0.20 0.75 0.20 0.05 0.20 - - -   Description C50 is a medium carbon steel is used when greater strength and hardness is desired than in the “as rolled” condition. Applications Quenched and subsequently tempered steel for screws, forgings, wheel tyres, shafts, sickles, axes, ...


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Port: Shenzhen
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    FAQ

    Product Tags



    Designation by Standards



    Brand Name Ravne No. Mat. No. DIN EN AISI
    C50 522 1.0540 C50 - 1050



    Chemical Composition (in weight %)



    C Si Mn Cr Mo Ni V W Others
    0.51 0.20 0.75 0.20 0.05 0.20 - - -



    Description
    C50 is a medium carbon steel is used when greater strength and hardness is desired than in the “as rolled” condition.

    Applications
    Quenched and subsequently tempered steel for screws, forgings, wheel tyres, shafts, sickles, axes, knives, wood working drills, hammers, etc.

    Physical properties (avarage values) at ambient temperature
    Modulus of elasticity [103 x N/mm2]: 205
    Density [g/cm3]: 7.85
    Specific heat capacity[J/g.K]: 0.48

    Coefficient of Linear Thermal Expansion 10-6 oC-1



    20-100oC 20-250oC 20-500oC
    11.5 13.0 14.0



    Soft Annealing
    Heat to 680-710oC, cool slowly in furnace.

    Normalizing
    Normalizing temperature: 840-880oC/air.

    Hardening
    Harden from a temperature of 820-860oC followed by water or oil quenching.

    Tempering
    Tempering temperature: 550-660oC/air.

    Forging
    Hot forming temperature: 1050-850oC.

    Machinability
    No data.

    Disclaimer
    The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
