Mat.No. 1.0501, DIN C35, AISI 1035
Designation by Standards Mat. No. DIN EN AISI 1.0501 C35 - 1035 Chemical Composition (in weight %) C Si Mn Cr Mo Ni V W Others 0.35 max. 0.40 0.65 max. 0.40 max. 0.10 max. 0.40 - - (Cr+Mo+Ni) = max. 0.63 Description Carbon steel, medium carbon steel. This steel grade has simular propeties as the steel CK35. Applications Applications include levers, bolts, studs, nuts, and similar parts which are headed, upset, or extruded. Applications for wires include nails requiring high sh...
Designation by Standards
Chemical Composition (in weight %)
|0.35||max. 0.40||0.65||max. 0.40||max. 0.10||max. 0.40||-||-||(Cr+Mo+Ni) = max. 0.63|
Description Carbon steel, medium carbon steel. This steel grade has simular propeties as the steel CK35. Applications Applications include levers, bolts, studs, nuts, and similar parts which are headed, upset, or extruded. Applications for wires include nails requiring high shank rigidity or strength and quench-hardened nails. Physical properties (avarage values) at ambient temperature Modulus of elasticity [103 x N/mm2]: 200 Density [g/cm3]: 7.87 Thermal conductivity [W/m.K]: 43.6 Coefficient of Linear Thermal Expansion 10-6 oC-1
Soft Annealing See the steel CK35. Stress Relieving See the steel CK35. Hardening See the steel CK35. Tempering See the steel CK35. Diagram Tempering Temperature – Mechanical Properties Forging Hot forming temperature: See the steel CK35. Machinability See the steel CK35. Disclaimer The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
