    Designation by Standards



    Mat. No. DIN EN AISI
    1.2562 142W13 - -



    Chemical Composition (in weight %)



    C Si Mn Cr Mo Ni V W Others
    1.43 0.23 0.30 0.35 - - 0.25 3.05 -



    Description
    Low alloyed W cold working tool steel.

    Applications
    Cutting tools, stamping, woodworking, drawing, deep drawing and pressing tools, cold working rolls, measuring tools.

    Physical properties (avarage values) at ambient temperature
    Modulus of elasticity [103 x N/mm2]: 210
    Density [g/cm3]: 8.0

    Soft Annealing
    Heat to 720-750oC, cool slowly in furnace. This will produce a maximum Brinell hardness of 270.

    Stress Relieving
    Stress relieving to remove machining stresses should be carried out by heating to approx. 650oC, holding for 1-2 hours at heat, followed by air cooling. This operation is performed to reduce distortion during heat treatment.

    Hardening
    Harden from a temperature of 800-830oC followed by water quenching. Hardness after quenching is 66 HRC.

    Tempering
    Tempering temperature: 100-250oC.

    Tempering Temperature (oC) vs. Hardness (HRC)



    100oC 150oC 200oC 250oC 300oC
    66 65 64 62 60



    Tempering Diagram

    Forging
    Hot forming temperature: 1050-850oC.

    Machinability
    No data.

    Disclaimer
    The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
