A516 Grade 60 Steel Plate
Short Description:
Bozhong is a A516 Grade 60 Steel Plate manufacturers, suppliers and stockists, delivering to the whole of the world.We are having largest inventory & ready stock of around 200 tons of A516 Grade 60 Steel Plate in different size, grades & cuts.Our manufacturing program is supported by intensive in-house product inspection and testing and accredited to meet all the most recognized international standards, including ISO 9001:2008 Bozhong specializes in A516 Grade...
Product Detail
FAQ
Product Tags
Bozhong is a A516 Grade 60 Steel Plate manufacturers, suppliers and stockists, delivering to the whole of the world.We are having largest inventory & ready stock of around 200 tons of A516 Grade 60 Steel Plate in different size, grades & cuts.Our manufacturing program is supported by intensive in-house product inspection and testing and accredited to meet all the most recognized international standards, including ISO 9001:2008
Bozhong specializes in A516 Grade 60 Steel Plate .With 25 years of experience in manufacturing A516 Grade 60 Steel Plate we offer high quality, lower cost but the best service. As a result to that our export account today is in over 45 countries some of them areIran, Saudi Arabia, United Arab Emirates, Singapore, Malaysia We welcome your inquiries.
We are specialized in offering precision engineered A516 steel plate, which are used in various engineering applications and can be availed in various grades like A516 Grade 60 Steel Plate , A516 Grade 65 Steel Plate , A516 Grade 70 Steel Plate, ASTM A516 GRADE 60 65 70 Plates Trippled Certified , ASTM A516 GRADE 60 70 Plates Dual Certified , A537 Class 1 Steel Plate, A537 Class 2 Steel Plate hese grades are available in the form of A516 Grade 60 Steel Plate
A516 Grade 60 Steel Plate supplied by us are accepted by clients in various spheres of the industries ranging from basic industries such as Sugar, Paper, Textile, Dairy, Engineering to more complex such as Oil & Gas, Petrochemical, Chemical & Fertilizers, Power Generation and Nuclear Industries.We are also have huge ready stock of Chrome Moly Steel Plate, Boiler Plate, HIC plate, Pressure Vessel Steel plate, Abrasion Resistant Steel Plates, Offshore & Structural Steel Plate, Quenched & Tempered Steel plate , High Nickel Alloy plate, Stainless Steel plate,Duplex Stainless Steel Plate, Clad plate, 16MO3 Steel Plate
ASTM A516 Grade 60 is a boiler plate to ASTM A516/A516M. This is the ASME/ASTM standard for pressure vessel steel plate for use at low and medium temperatures; typically where improved Charpy V-notch testing is important. Simply put these plates are remain tough when holding low temperature fluids or gases under pressure.At Bozhong we stock large numbers of ASTM A516 Grade 60 steel plates to ensure that we always have high availability of plates to meet customers requirements.
The material is used extensively by industrial boiler and pressure vessel fabricators who provide manufacturing support to the oil, gas and petrochemical industry. The steel has good weldability and excellent notch toughness. At Bozhong we keep a healthy stock of ASTM A516 Grade 60 carbon steel plates. These plates come with mill certification in compliance with EN10204 3.1 or EN10204 3.2. and are hard stamped and fully traceable. Alternatively we can ship to you directly from the mill.
The most important thing to know as a potential customer of bozhong is that we stock, process, and distribute all of the popular grades of Boiler and Pressure Vessel specifications like A516 Grade 60 Steel Plate , A516 Grade 65 Steel Plate , A516 Grade 70 Steel Plate, ASTM A516 GRADE 60 65 70 Plates Trippled Certified , ASTM A516 GRADE 60 70 Plates Dual Certified , A537 Class 1 Steel Plate, A537 Class 2 Steel Plate
Pressure Vessel Steel Plate Grade and Specification
| Item | Pressure Vessel Steel Plate |
| Material | A516 Grade 60 Steel Plate , A516 Grade 65 Steel Plate , A516 Grade 70 Steel Plate, ASTM A516 GRADE 60 65 70 Plates Trippled Certified , ASTM A516 GRADE 60 70 Plates Dual Certified , A537 Class 1 Steel Plate, A537 Class 2 Steel Plate |
| Thickness | 5mm to 150mm |
| Width | 1,500mm to 2,500mm |
| Length | 6,000mm to 12,000mm |
| Export to | Iran, Saudi Arabia, United Arab Emirates, Singapore, Malaysia |
A516 Grade 60 Steel Plate Properties
Chemical Composition of ASTM A516 Grade 60 Steel Plate
| Carbon (C) | % | Manganese (Mn) | % | Phosphorus (P) | % |
|
12.5mm or less12.5 – 50mm 50 – 100mm 100 – 200mm > 200mm |
0.210.23 0.25 0.27 0.27 |
12.5mm or less• Heat Analysis : • Product Analysis : Over 12.5mm • Heat Analysis : • Product Analysis : |
0.6-0.90.55-0.980.85-1.20 0.79-1.30 |
(max) | 0.035 |
| Sulphur (S) | % | Silicon (Si) | % | ||
| (max) | 0.035 |
• Heat Analysis :• Product Analysis : |
0.15-0.400.13-0.45 |
||
(Maximum values unless stated otherwise)
Mechanical Properties of ASTM A516 Grade 60 Steel Plate
| Description | Grade 60 |
|
Tensile strength (ksi)Tensile strength (MPa) Yield strength (ksi) Yield strength (MPa) Elongation in 200mm (min)(%) Elongation in 50mm (min) (%) Thickness (max)(mm) |
60-80415-550 32 220 21 25 205 |
All Steel Grades Chart for Boiler steel plate:
| STANDARD | STEEL GRADE |
| EN10028 | P235GH,P265GH,P295GH,P355GH,16Mo3P275N,P275NH,P275NL1, P275NL2,P355N,P355NH,P355NL1,P355NL2,P460N,P460NH, P460NL1,P460NL2P355Q, P355QH,P355QL1,P355QL2,P460Q,P460QH,P460QL1,P460QL2, P500Q,P500QH,P500QL1,P500QL2,P690Q,P690QH,P690QL1,P690QL2P355M,P355ML1,P355ML2,P420M,P420ML1, P420ML2,P460M,P460ML1,P460ML2 |
| DIN 17155 | HI,HII,17Mn4,19Mn6,15Mo3,13CrMo44,10CrMo910 |
| ASMEASTM | A203/A203M SA203/SA203MA203 Grade E,A203 Grade F,A203 Grade D, A203 Grade B,A203 Grade ASA203 Grade E,SA203 Grade F,SA203 Grade D, SA203 Grade B,SA203 Grade AA204/A204M SA204/SA204MA204 Grade A, A204 Grade B,A204 Grade CSA204 Grade A,SA204 Grade B,SA204 Grade CA285/A285M A285 Grade A,A285 Grade B,A285 Grade CSA285/SA285M SA285 Grade A,SA285 Grade B,SA285 Grade CA299/A299M A299 Grade A,A299 Grade BSA299/SA299M SA299 Grade A,SA299 Grade B
A302/A302M SA302/SA302M A302 Grade A,A302 Grade B,A302 Grade C,A302 Grade D SA302 Grade A,SA302 Grade B,SA302 Grade C,SA302 Grade D A387/A387M SA387/SA387M A387Gr11CL1,A387Gr11CL2,A387Gr12CL1, A387Gr12CL2,A387Gr22CL1,A387Gr22CL2 SA387Gr11CL1,SA387Gr11CL2,SA387Gr12CL1, SA387Gr12CL2,SA387Gr22CL1,SA387Gr22CL2 A455/A455M A455, SA455/SA455M SA455 A515/A515M SA515/SA515M A515 Grade 60,A515 Grade 65,A515 Grade 70 SA515 Grade 60,SA515 Grade 65,SA515 Grade 70 A516/A516M SA516/SA516M A516 Grade 55,A516 Grade 60,A516 Grade 65,A516 Grade 70 SA516 Grade 55,SA516 Grade 60,SA516 Grade 65,SA516 Grade 70 A533/A533M SA533/SA533M A533GrA CL1/CL2/CL3,A533GrB CL1/CL2/CL3, A533GrC CL1/CL2/CL3,A533GrD CL1/CL2/CL3 SA533GrA CL1/CL2/CL3,SA533GrB CL1/CL2/CL3, SA533GrC CL1/CL2/CL3,SA533GrD CL1/CL2/CL3 A537/A537M A537CL1,A537CL2,A537CL3 SA537/SA537M SA537CL1,A537CL2,A537CL3 |
| JIS G3103JIS G3115 | SB410,SB450,SB480,SB450M,SB480MSPV235,SPV315,SPV355,SPV410, SPV450, SPV490 |
| GB713GB3531 | Q245R(20R),Q345R(16MnR),Q370R,18MnMoNbR,13MnNiMoR,15CrMoR, 14Cr1MoR, 12Cr2Mo1R,12Cr1MoVR16MnDR,15MnNiDR,09MnNiDR |
Typical Application of A516 Grade 60 Steel Plate
- Boilers
- Calorifiers
- Columns
- Dished Ends
- Filters
- Flanges
- Heat exchangers
- Pipelines
- Pressure vessels
- Storage tanks
- Valves
