A516 Grade 55 Steel Plate

A516 Grade 55 Steel Plate

Short Description:

Specification for Boiler Quality Steel Plates & Sheets Thickness 3 mm to 200 mm Width 1250mm to 4000mm Length Up to 20,000 mm Certification DUAL CERTIFICATION [SA 516 GR. 60 / 70] TRIPLE CERTIFICATION. [SA 516 GR. 60 / 65 / 70] IBR AND NON IBR   Chemical Analysis for Boiler Quality Steel Plates C Mn P max S max Si max t < 12.5 mm 12.5mm < t =50mm 50mm < t ≤ 100mm 100mm < t ≤ 200mm t < 200 mm t < 12.5 mm t 12s.5 mm A516 Grade 55 0.18 0.2 0.22 0...


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Port: Shenzhen
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    FAQ

    Product Tags

    Specification for Boiler Quality Steel Plates & Sheets

    Thickness 3 mm to 200 mm
    Width 1250mm to 4000mm
    Length Up to 20,000 mm
    Certification DUAL CERTIFICATION [SA 516 GR. 60 / 70]
    TRIPLE CERTIFICATION. [SA 516 GR. 60 / 65 / 70]
    IBR AND NON IBR



    Chemical Analysis for Boiler Quality Steel Plates

    C Mn P max S max Si max
    t < 12.5
    mm
    12.5mm < t =50mm 50mm < t ≤ 100mm 100mm < t ≤ 200mm t < 200
    mm
    t < 12.5
    mm
    t 12s.5
    mm
    A516 Grade 55 0.18 0.2 0.22 0.24 0.26 06-09 0.55-0.98 0.035 0.035 0.15-0.4
    A516 Grade 60 0.21 0.23 0.25 0.27 0.27 06-09 0.85-1.2 0.035 0.035 0.15-0.4
    A516 Grade 65 0.24 0.26 0.28 0.29 0.29 0.85-1.2 0.85-1.2 0.035 0.035 0.15-0.4
    A516 Grade 70 0.27 0.28 0.3 0.31 0.31 0.85-1.2 0.85-1.2 0.035 0.035 0.15-0.4



    Tensile Requirements for Boiler Quality Steel Plates

    Tensile Strength (ksi) Tensile Strength (MPa) Yield Strength (ksi) Yield Strength (MPa) Elongation in 200mm(%) Elongation in 50mm(%)
    A516 Grade 55 55-75 380-515 30 205 23 27
    A516 Grade 60 60-80 415-550 32 220 21 25
    A516 Grade 65 65-85 450-585 35 240 19 23
    A516 Grade 70 70-90 485-620 38 260 17 21



    Applications

    - Aerospace Industry
    - Nuclear Power Plant Industry
    - Chemical Industry
    - Refineries Industry
    - Paper Industry
