A106 PIPE S/A106 NPS 1/4″- 30″

A106 PIPE  S/A106 NPS 1/4″- 30″

Short Description:

S/A106 NPS 1/4″- 30″ Schedules 10 through 160, STD, XH and XXH ASTM A106 seamless pressure pipe (also known as ASME SA106 pipe) is commonly used in the construction of oil and gas refineries, power plants, petrochemical plants, boilers, and ships where the piping must transport fluids and gases that exhibit higher temperatures and pressure levels. American Piping Products stocks a full range of A106 pipe (SA106 Pipe) in: Grades B and C NPS ¼” to 30” diameter Schedules 10 through 160, STD, XH...


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Port: Shenzhen
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    FAQ

    Product Tags

    S/A106
    NPS 1/4″- 30″
    Schedules 10 through 160, STD, XH and XXH

    ASTM A106 seamless pressure pipe (also known as ASME SA106 pipe) is commonly used in the construction of oil and gas refineries, power plants, petrochemical plants, boilers, and ships where the piping must transport fluids and gases that exhibit higher temperatures and pressure levels.

    American Piping Products stocks a full range of A106 pipe (SA106 Pipe) in:

    • Grades B and C
    • NPS ¼” to 30” diameter
    • Schedules 10 through 160, STD, XH and XXH
    • Schedules 20 through XXH
    • Wall Thickness beyond XXH, including:
      – Up to 4” wall in 20” through 24” OD
      – Up to 3” wall in 10” through 18” OD
      – Up to 2” wall in 4” through 8” OD

    S/A 106 Grade B specs are listed below. If you’re looking for Grade B-specific product offerings,

    ASTM A106 Seamless Pressure Pipe (also known as ASME SA106 pipe) covers seamless carbon steel nominal wall pipe for high-temperature service. Suitable for bending, flanging and similar forming operations.

    NPS 1-1/2″ and under may be either hot finished or cold drawn. NPS 2″ and larger shall be hot finished unless otherwise specified.

    Looking for specific post-production services? See our full list.

    Process

    Killed steel, with primary melting process being open-hearth, basic-oxygen, or electric-furnace, possibly combined with separate degassing or refining.

    Steel cast in ingots or strand cast is permissible.

    Hot-finished pipe need not be heat treated.

    Cold-drawn pipe shall be heat treated after the final cold draw pass.

    Chemical Requirements

    Download Chart
    Grade A Grade B Grade C
    Carbon max. % 0.25 0.30 0.35
    *Manganese % 0.27 to 0.93 *0.29 to 1.06 0.29 to 1.06
    Phosphorous, max. % 0.035 0.035 0.035
    Sulfur, max. % 0.035 0.035 0.035
    Silicon, min.% 0.10 0.10 0.10
    Chrome, max. % 0.40 0.40 0.40
    Copper, max. % 0.40 0.40 0.40
    Molybdenum, max. % 0.15 0.15 0.15
    Nickel, max. % 0.40 0.40 0.40
    Vanadium, max.% 0.08 0.08 0.08
